DS200DCFBG1BLC GE Incentive Card – Designed specifically for EX2000, with unparalleled reliability!
The GE DS200DCFBG1BLC is a crucial Digital Control Feedback Board specifically engineered for GE’s industrial control systems, particularly the renowned Mark VIe Speedtronic systems. As an integral part of GE’s advanced automation and control product line, this board serves as a key element in ensuring accurate feedback and control within complex industrial setups.
The DS200DCFBG1BLC is responsible for collecting and processing feedback signals from various sensors in the system. It converts these real – world physical measurements into digital data that can be easily interpreted by the main control unit. With its 12 – bit signal resolution and a 100ms update rate, it provides precise and timely information, enabling the control system to make accurate adjustments. This board is essential for maintaining the stability and efficiency of industrial processes, whether it’s in power generation, oil and gas, or other heavy – industry applications that rely on GE’s control systems.
| Parameter name | Parameter value |
| Product model | DS200DCFBG1BLC |
| Manufacturer | GE |
| Product category | Digital Control Feedback Board |
| Electrical performance | Input voltage range: 10 – 30V DC, Power consumption: ≤15W |
| Physical size | 200mm x 150mm x 30mm |
| Interface type | Multiple terminal blocks for signal connection, J1, J2 connectors |
| Communication protocol | Proprietary communication protocol for GE systems |
| Environmental requirements | Operating temperature: 0°C – 50°C, Relative humidity: 5% – 95% non – condensing |
| Installation method | Rack – mounted, requires specific GE rack |
| Performance indicators | Signal resolution: 12 – bit, Update rate: 100ms |
| Compatibility | Designed for use with GE Mark VIe Speedtronic systems |
Core advantages and technical highlights
High – precision signal processing
The GE DS200DCFBG1BLC excels in high – precision signal processing. Its 12 – bit resolution ensures that even the slightest changes in the feedback signals are accurately captured. This level of precision is vital in industrial applications where small variations can have a significant impact on the overall performance of the system. Whether it’s monitoring the speed of a turbine or the pressure in a pipeline, the board provides reliable and detailed data for effective control.
System – specific compatibility
Designed exclusively for GE Mark VIe Speedtronic systems, the DS200DCFBG1BLC offers seamless integration. It works in harmony with other components of the system, eliminating the need for complex customizations. This compatibility ensures that the board can be quickly installed and commissioned, reducing downtime during system upgrades or maintenance. It also guarantees that the system operates at its optimal performance, as all components are designed to work together flawlessly.
Robust and reliable design
Built to withstand the harsh conditions of industrial environments, the DS200DCFBG1BLC features a robust design. It can operate within a temperature range of 0°C – 50°C and handle relative humidity levels from 5% – 95% non – condensing. The use of high – quality materials and strict manufacturing standards ensures its long – term reliability, minimizing the risk of failures and reducing maintenance costs over the product’s lifespan.
Typical application scenarios
In power generation plants, the GE DS200DCFBG1BLC plays a critical role in the control of gas and steam turbines. It monitors key parameters such as turbine speed, temperature, and vibration, providing real – time feedback to the control system. This allows operators to optimize the performance of the turbines, ensuring maximum power output while maintaining safety.
In the oil and gas industry, this board is used in the control of pumps, compressors, and other critical equipment. It helps in maintaining the proper flow rates and pressures within pipelines, preventing over – or under – pressurization that could lead to costly disruptions or safety hazards. By accurately processing feedback signals, the DS200DCFBG1BLC enables the automation of processes, improving efficiency and reducing the need for manual intervention.
For industrial machinery in manufacturing facilities, the board can be used to control the speed and position of motors, ensuring precise movement and accurate production. It contributes to the overall quality control of the manufacturing process by providing reliable feedback on the performance of the machinery.
Related model recommendations
- DS200DCFAG1A: Similar in function to the DS200DCFBG1BLC, but with a slightly different design and set of features. It can be considered as an alternative for certain applications within the GE Mark VIe system, offering a comparable level of performance in signal processing.
- DS200DCFCH1A: Part of the same family of control feedback boards, this model has enhanced communication capabilities. It can be used in more complex networked control systems where data transfer speed and reliability are crucial, and can work in conjunction with the DS200DCFBG1BLCfor larger – scale applications.
- DS200DCFEH1A: A more advanced version with higher signal resolution and faster update rates. It is suitable for applications that require extremely precise control, such as high – tech manufacturing processes or research facilities using GE control systems, and can be seen as an upgrade option for the DS200DCFBG1BLCin some cases.
- DS200DCFFH1A: This model is designed for applications with specific environmental requirements. It has a wider operating temperature range and improved resistance to electromagnetic interference, making it a good choice for installations in harsh or noisy industrial environments, and can replace the DS200DCFBG1BLCwhen such conditions are present.
- DS200DCFJH1A: Focuses on power efficiency while maintaining reliable performance. It can be used in applications where power consumption is a concern, such as remote or battery – powered industrial monitoring systems, and can be an alternative to the DS200DCFBG1BLCin energy – sensitive setups.
